型号Model

HM2514MP5

像机尺寸Image Size

2/3-inch

焦距Focal length

25mm

光圈范围F No.

F1.4-16

最短物距M.O.D(m)

0.2-Inf.

控制方式Operation

Iris

Manual手动调整

Focus

Manual手动调整

视场角Horizontal Angle of View　(D×H×V)

2/3"Type

24.8°×20.0°×15.0°

1/2"Type

18.1°×14.5°×11.1°

畸变Distortion

2/3"Type

<0.2%@y=5.5mm

1/2"Type

<0.3%@y=4.0mm

后焦距Back focal length

12.78mm

接口Mount

C-Mount

外形尺寸Dimension

Φ32×36.3mm

重量Weight

133.0g

分辨率Horizontal Resolution

5MP

滤镜尺寸Filter Thread

M30.5x 0.5

工作温度Working Temperature

-20ºC ～ +60ºC
